LSZH Jacket | Aramid Fiber Sheath | Ideal for SANs, data servers, SFP+This OM3 LC to LC Multimode Duplex Fiber Optic Patch cable features 50/125 micron fiber and supports high-bandwidth data transmission over a 10 Gigabit Ethernet connection.Built for PerformanceWith laser-optimized multimode fiber (LOMMF), the patch cable is ideal for connecting 850 nm Vertical Cavity Surface Emitting Laser (VCSEL) and LED sources. The high-speed connectivity on the aqua fiber-optic cable provides a high-bandwidth solution for your data centers or high-density applications.Reliable ConnectionEach OM3 fiber cable is individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.High-Quality ConstructionHoused in a LSZH (Low-Smoke, Zero-Halogen) flame retardant jacket, this fiber-optic cable ensures minimal smoke, toxicity and corrosion when exposed to high sources of heat, or in the event of a fire. It's the best choice for a wide range of environments, including industrial settings, central offices and schools, as well as residential settings where building codes are a consideration.A50FBLCLC7 is backed by a StarTech.com lifetime warranty and free lifetime technical support.The StarTech.com Advantage
Design
Product colour Aqua colour
Features
Cable length 7 m
Cladding diameter 125 µm
Connector 1 LC
Connector 1 gender Male
Connector 2 LC
Connector 2 gender Male
Core diameter 50 µm
Fiber mode structure Multi-mode
Fibre optic type OM3
Full duplex Y
Jacket material Low smoke zero halogen (LSZH)
Wavelengths supported 850 nm
Logistics data
Harmonized System (HS) code 85447000
Master (outer) case height 435 mm
Master (outer) case length 410 mm
Master (outer) case width 410 mm
Products per master (outer) case 120 pc(s)
Operational conditions
Operating temperature (T-T) -20 - 60 °C
Storage temperature (T-T) -20 - 60 °C
Other features
Data transfer rate 100 Gbit/s
Packaging data
Quantity per pack 1 pc(s)
Sustainability
Sustainability certificates RoHS, CE
Technical details
Doesn't contain Halogen
Weight & dimensions
Package depth 200 mm
Package height 20 mm
Package weight 106 g
Package width 215 mm
Weight 96 g
