The VESA-compliant DWM2655M Swivel/Tilt Wall Mount allows you to mount your flat-panel television, monitor or other display on the wall. Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants, it fits most flat-panel displays from 26 to 55 inches.

Adjust the display’s viewing angle to fit your environment and comfort level. A 120° swivel, -15° to +15° tilt and -5° to +5° screen level adjustment capability minimizes glare and provides comfortable viewing from multiple angles.

Durable all-metal frame with scratch-resistant powder-coated finish supports up to 110 lbs (49.9 kgs). Mounting hardware included. Built-in bubble level allows accurate display leveling. Conforms to VESA-compliant displays with any of the following mounting hole patterns: 100 x 100 mm, 100 x 200 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm and 400 x 400 mm

Mounts Your TV or Monitor to the Wall
Fits most flat-panel televisions, monitors and other displays from 26 to 55 in.
Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants
Viewing angle adjusts to fit your environment and comfort level
Mounting hardware included

Convenient One-Touch Adjustment
120° swivel, -15° to +15° tilt and -5° to +5° screen level adjustment capability provides comfortable viewing from multiple angles

Durable Metal Construction
Supports up to 110 lbs (49.9 kgs)
Scratch-resistant powder-coated finish blends with any décor
Built-in bubble level allows accurate display leveling

VESA Compliance
Supports the following VESA mounting hole patterns: 100 x 100 mm, 100 x 200 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm and 400 x 400 mm
Design
Country of origin China
Panel mounting interface 200 x 200,300 x 300,400 x 200,400 x 400
Product colour Black
Display
Tilt angle range -15 - 15°
Ergonomics
Swivel angle 120°
Features
Cable management N
Maximum screen size 139.7 cm (55")
Maximum weight capacity 49.8 kg
Graphics
Number of displays supported 1
Logistics data
Harmonized System (HS) code 85299097
Master (outer) case gross weight 17.4 kg
Master (outer) case GTIN (EAN/UPC) 10037332183634
Master (outer) case height 248.9 mm
Master (outer) case length 254 mm
Master (outer) case width 569 mm
Products per master (outer) case 2 pc(s)
Mounting
Maximum VESA mount 400 x 400 mm
Minimum VESA mount 200 x 200 mm
Mounting type Wall
Other features
Minimum screen size 66 cm (26")
Packaging content
Manual Y
Packaging data
Mounting kit Y
Sustainability
Sustainability certificates RoHS
Weight & dimensions
Depth 428 mm
Height 194.8 mm
Package depth 233.7 mm
Package height 116.8 mm
Package weight 8.65 kg
Package width 556.3 mm
Weight 8.02 kg
Width 428 mm

Write a review

Please login or register to review

Tripp Lite DWM2655M Swivel/Tilt Wall Mount for 26" to 55" TVs and Monitors

  • Brand: Tripp-Lite
  • Product Code: DWM2655M
  • Availability: In Stock
  • $117.82
