This fiber network card delivers reliable, high-performance network connectivity, by adding an open SFP+ slot to your server or high-powered workstation. It provides an easy and cost-effective way to upgrade your server or workstation to a 10 Gigabit fiber network using the SFP+ module of your choice and gives you the flexibility to use either multimode or single-mode fiber.

Increase your network speed
Several factors drive the need for more bandwidth in your network infrastructure. An increase in the number of network users and data-intensive applications, such as multimedia streaming and large file transfers all contribute to the need for more bandwidth in your network infrastructure. This fiber NIC lets you take advantage of the increased speed and stability of a 10 Gigabit network, with data transfers of up to 10Gbps.

Add scalable network connections to your server or workstation
The fiber NIC is compatible with most 10GbE SFP+ transceivers. This gives you flexible and scalable configuration options for connecting your computer directly to a fiber network, at greater distances.

The card features an open SFP+ slot with support for one interchangeable 10GBase SFP+ module. This gives you the option to use the fiber transceiver module that best suits your network needs based on distance and connector type. StarTech.com offers a variety of SFP+ transceiver modules including the SFP10GLRST single-mode SFP+ the SFP10GLRMST multi-mode SFP+, and SFP10GSRST multimode LC with DDM.

In addition, StarTech.com SFP+ Cables provide a dependable solution for linking telecom and data communications equipment, such as routers and switches.

Enhance your network capabilities
The 10 Gigabit network card features the Intel® 82599 chipset, delivering the power, performance and enhanced capabilities you need for reliable network connections to your server or computer. The Intel chip offers many advanced features including Intel® Virtualization Technology for Connectivity, PXE network boot support and up to 15K jumbo frame support.

The PEX10000SFPI is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Data transmission
Maximum data transfer rate 10000 Mbit/s
Design
Certification CE, FCC, REACH
Component for PC
Product colour Black
Features
Chipset Intel® 82599
Full duplex Y
Keyboard
Connectivity technology Wired
Logistics data
Harmonized System (HS) code 85176990
Master (outer) case height 309 mm
Master (outer) case length 585 mm
Master (outer) case width 359 mm
Products per master (outer) case 80 pc(s)
Network
Flow control support Y
Jumbo frames 15000
Jumbo frames support Y
VLAN tagging Y
Operational conditions
Operating relative humidity (H-H) 20 - 80%
Operating temperature (T-T) 5 - 50 °C
Storage temperature (T-T) -20 - 60 °C
Other features
Internal Y
Quick start guide Y
Packaging data
Low-profile bracket Y
Performance
Fiber ethernet cabling technology 10GBASE-LR, 10GBASE-LRM, 10GBASE-SR
Fiber optic connector SFP+
Linux operating systems supported Y
Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Ports & interfaces
Fiber ports quantity 1
Host interface PCI Express
Interface Fiber
PCI version 2.0
Sustainability
Sustainability certificates CE, RoHS
Sustainability compliance Y
System requirements
Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Technical details
Networking standards IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3aq, IEEE 802.3x
Weight & dimensions
Depth 135 mm
Height 120 mm
Package depth 172 mm
Package height 32 mm
Package weight 178 g
Package width 142 mm
Weight 102 g
Width 18 mm

Write a review

Please login or register to review

StarTech.com 1-Port 10G Open SFP+ Network Card - PCIe - Intel Chip - MM/SM

  • Brand: StarTech.com
  • Product Code: PEX10000SFPI
  • Availability: In Stock
  • $277.27
