| Box |
Yes |
| Cooler included |
Yes |
| Maximum internal memory supported by processor |
192 GB |
| Maximum number of DMI lanes |
8 |
| Maximum number of PCI Express lanes |
20 |
| Maximum turbo power |
110 W |
| Memory bandwidth supported by processor (max) |
76.8 GB/s |
| Memory types supported by processor |
DDR4-SDRAM, DDR5-SDRAM |
| PCI Express configurations |
1x16+1x4, 2x8+1x4 |
| Performance cores |
4 |
| Performance-core base frequency |
3.5 GHz |
| Performance-core boost frequency |
4.7 GHz |
| Processor base power |
58 W |
| Processor boost frequency |
4.7 GHz |
| Processor cache |
12 MB |
| Processor cache type |
Smart Cache |
| Processor codename |
Raptor Lake |
| Processor cores |
4 |
| Processor family |
Intel® Core™ i3 |
| Processor generation |
Intel Core i3-14xxx |
| Processor manufacturer |
Intel |
| Processor model |
i3-14100F |
| Processor operating modes |
64-bit |
| Processor socket |
LGA 1700 |
| Processor threads |
8 |
| Stepping |
H0 |
| Tjunction |
100 °C |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Enhanced Intel SpeedStep Technology |
Yes |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Boot Guard |
Yes |
| Intel® Control-flow Enforcement Technology (CET) |
Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® OS Guard |
Yes |
| Intel® Secure Key |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Standard Manageability (ISM) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Volume Management Device (VMD) |
Yes |
| Mode-based Execute Control (MBE) |
Yes |
| Processor ARK ID |
236786 |
| Processor package size |
45 x 37.5 mm |
| Scalability |
1S |
| Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
| Thermal Monitoring Technologies |
Yes |
