Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration. Visit www.intel.com/OptaneMemory for configuration requirements.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration. Visit www.intel.com/OptaneMemory for configuration requirements.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
| Design | |
| Status | Launched |
| Expansion slots | |
| PCI Express slots version | 4.0, 5.0 |
| Features | |
| Direct Media Interface (DMI) Revision | 4.0 |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet |
| Graphics | |
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| Multi-Format Codec Engines | 2 |
| Number of displays supported (on-board graphics) | 4 |
| Number of execution units | 32 |
| On-board graphics card | Y |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card dynamic frequency (max) | 1550 MHz |
| On-board graphics card ID | 0x4680 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat | 5120 x 3200 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| On-board graphics card refresh rate at maximum resolution (Displ | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - | 120 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| Logistics data | |
| Harmonized System (HS) code | 85423119 |
| Memory | |
| ECC | Y |
| Maximum internal memory | 128 GB |
| Memory bandwidth (max) | 76.8 GB/s |
| Memory channels | Dual-channel |
| Other features | |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Launch date | Q1'22 |
| Target market | Gaming, Content Creation |
| Performance | |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Processor | |
| Box | Y |
| Bus type | DMI4 |
| Efficient cores | 8 |
| Efficient-core base frequency | 2.5 GHz |
| Efficient-core boost frequency | 4 GHz |
| Maximum internal memory supported by processor | 128 GB |
| Maximum number of DMI lanes | 8 |
| Maximum number of PCI Express lanes | 20 |
| Maximum turbo power | 241 W |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Performance cores | 8 |
| Performance-core base frequency | 3.4 GHz |
| Performance-core boost frequency | 5.2 GHz |
| Processor base power | 150 W |
| Processor boost frequency | 5.5 GHz |
| Processor cache | 30 MB |
| Processor cache type | Smart Cache |
| Processor codename | Alder Lake |
| Processor cores | 16 |
| Processor family | Intel® Core™ i9 |
| Processor generation | 12th gen Intel® Core™ i9 |
| Processor manufacturer | Intel |
| Processor model | i9-12900KS |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1700 |
| Processor threads | 24 |
| Tjunction | 90 °C |
| Processor special features | |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Trusted Execution Technology | Y |
| Intel Turbo Boost Max Technology 3.0 | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel vPro® Enterprise Platform Eligibility | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® Active Management Technology (Intel® AMT) | Y |
| Intel® Adaptive Boost Technology | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Boot Guard | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® Control-flow Enforcement Technology (CET) | Y |
| Intel® Deep Learning Boost (Intel® DL Boost) | Y |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Y |
| Intel® Hardware Shield Eligibility | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® One-Click Recovery | Y |
| Intel® Optane™ Memory Ready | Y |
| Intel® OS Guard | Y |
| Intel® Quick Sync Video Technology | Y |
| Intel® Secure Key | Y |
| Intel® Speed Shift Technology | Y |
| Intel® Standard Manageability (ISM) | Y |
| Intel® Thermal Velocity Boost | Y |
| Intel® Thermal Velocity Boost Frequency | 5.5 GHz |
| Intel® Thermal Velocity Boost Temperature | 50 °C |
| Intel® Thread Director | Y |
| Intel® Threat Detection Technology (TDT) | Y |
| Intel® Total Memory Encryption | Y |
| Intel® Total Memory Encryption - Multi Key | Y |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.3 GHz |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Virtualization Technology with Redirect Protection (VT-rp | Y |
| Intel® Volume Management Device (VMD) | Y |
| Intel® vPro™ Platform Eligibility | Y |
| Mode-based Execute Control (MBE) | Y |
| Processor ARK ID | 225916 |
| Processor package size | 45 x 37.5 mm |
| Scalability | 1S |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Thermal Monitoring Technologies | Y |
| Technical details | |
| OpenCL version | 2.1 |
| Weight & dimensions | |
| Package type | Retail box |
Intel Core i9-12900KS processor 30 MB Smart Cache Box
- Brand: Intel
- Product Code: BX8071512900KS
- Availability: In Stock
-
$814.63
