Smart performance and design
An intelligent, performance-optimized, space-saving small form factor.
An intelligent, performance-optimized, space-saving small form factor.
| Audio | |
| Audio system | Waves MaxxAudio |
| Built-in speaker(s) | No |
| Design | |
| Chassis type | SFF |
| Introduction year | 2022 |
| Market positioning | Business |
| Placement supported | Vertical |
| Product colour | Black |
| Product type | Workstation |
| Viewing window | No |
| Water cooling system | No |
| Expansion slots | |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| Graphics | |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Memory | |
| ECC | No |
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| Memory data transfer rate | 5600 MT/s |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
| Non-ECC | Yes |
| Network | |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000,2500,100 Mbit/s |
| Wi-Fi | No |
| Operational conditions | |
| Non-operating altitude | 0 - 10668 m |
| Non-operating shock | 105 G |
| Non-operating vibration | 1.37 G |
| Operating altitude | 0 - 3048 m |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating vibration | 0.26 G |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 65 °C |
| Packaging content | |
| Cables included | AC |
| Display included | No |
| Performance | |
| Motherboard chipset | Intel W680 |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Number of front audio ports | 1 |
| Number of front USB ports | 4 |
| Number of rear audio ports | 1 |
| Number of rear USB ports | 6 |
| Number of SATA III connectors | 3 |
| Number of USB ports with PowerShare support | 1 |
| PowerShare | Yes |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Power | |
| 80 PLUS certification | 80 PLUS Platinum |
| Power supply | 300 W |
| Power supply input frequency | 47/63 Hz |
| Power supply input voltage | 90 - 264 V |
| Processor | |
| Efficient cores | 12 |
| Efficient-core base frequency | 1.5 GHz |
| Efficient-core Max Turbo Frequency | 4.2 GHz |
| Maximum turbo power | 219 W |
| Number of processors installed | 1 |
| Performance cores | 8 |
| Performance-core base frequency | 2.1 GHz |
| Performance-core Max Turbo Frequency | 5.3 GHz |
| Processor base power | 65 W |
| Processor boost frequency | 5.4 GHz |
| Processor cache | 33 MB |
| Processor cache type | Smart Cache |
| Processor cores | 20 |
| Processor family | Intel® Core™ i7 |
| Processor generation | Intel® Core™ i7 (14th gen) |
| Processor manufacturer | Intel |
| Processor model | i7-14700 |
| Processor threads | 28 |
| Security | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Storage | |
| Number of SSDs installed | 1 |
| Number of storage drives installed | 1 |
| NVMe | Yes |
| Optical drive type | DVD±RW |
| SSD capacity | 512 GB |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| SSD performance class | 40 |
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Total storage capacity | 512 GB |
| Weight & dimensions | |
| Depth | 292.8 mm |
| Height | 290 mm |
| Weight | 5.38 kg |
| Width | 92.6 mm |
DELL Precision 3460 Intel® Core™ i7 i7-14700 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro SFF Workstation Black
- Brand: Dell
- Product Code: J4XY9
- Availability: In Stock
-
$1,408.34
