Peak Processing Performance
No program is too intricate, and no file is too massive to hinder the Lenovo ThinkCentre M90s Gen 5 (Intel) small form factor (SFF) from operating at the speed of human imagination. With cutting-edge Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop delivers real-world, top-notch performance for business needs.
Confidently Secured
Lenovo ThinkShield offers thorough security, combining hardware and software to protect your data. The discrete Trusted Platform Module (dTPM) chip encrypts passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access through peripherals. Leveraging the Intel vPro® platform, this device enhances data and asset security.
Expandable Flexibility
The Smart Cable offers cutting-edge device collaboration through convenient USB-A and USB-C® connections, accommodating all your peripherals, including laptops and tablets. Seamlessly share device control, data, and screen projection between devices with this intelligent feature, supporting high-speed USB-C® data transfers.
Environmentally Aware
This small form factor PC was crafted with a strong emphasis on recycling. Our commitment to sustainability is evident in the integration of recycled post-consumer content (PCC) into various components. The packaging is thoughtfully designed using a combination of recycled and sustainably sourced materials.
No program is too intricate, and no file is too massive to hinder the Lenovo ThinkCentre M90s Gen 5 (Intel) small form factor (SFF) from operating at the speed of human imagination. With cutting-edge Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop delivers real-world, top-notch performance for business needs.
Confidently Secured
Lenovo ThinkShield offers thorough security, combining hardware and software to protect your data. The discrete Trusted Platform Module (dTPM) chip encrypts passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access through peripherals. Leveraging the Intel vPro® platform, this device enhances data and asset security.
Expandable Flexibility
The Smart Cable offers cutting-edge device collaboration through convenient USB-A and USB-C® connections, accommodating all your peripherals, including laptops and tablets. Seamlessly share device control, data, and screen projection between devices with this intelligent feature, supporting high-speed USB-C® data transfers.
Environmentally Aware
This small form factor PC was crafted with a strong emphasis on recycling. Our commitment to sustainability is evident in the integration of recycled post-consumer content (PCC) into various components. The packaging is thoughtfully designed using a combination of recycled and sustainably sourced materials.
| Audio | |
| Audio chip | Realtek ALC897Q-CG |
| Audio system | High Definition Audio |
| Built-in speaker(s) | Yes |
| Design | |
| Certification | MIL-STD-810H ENERGY STAR 8.0 EPEAT Gold Registered ErP Lot 3 GREENGUARD RoHS compliant TCO Certified 9.0 |
| Chassis type | SFF |
| Colour name | Black |
| Placement supported | Vertical |
| Product colour | Black |
| Product type | PC |
| Volume | 8.2 L |
| Graphics | |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Memory | |
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 128 GB |
| Memory channels | Dual-channel |
| Memory clock speed | 4400 MHz |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 4x DIMM |
| Network | |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Operational conditions | |
| Non-operating altitude | 0 - 12192 m |
| Operating altitude | 0 - 3048 m |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
| Packaging content | |
| Display included | No |
| Keyboard connectivity | Wired |
| Keyboard included | Yes |
| Mouse connectivity | Wired |
| Mouse included | Yes |
| Performance | |
| Motherboard chipset | Intel Q670 |
| Number of speakers | 1 |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| DisplayPorts quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Line-out | Yes |
| Microphone in | Yes |
| Thunderbolt 3 ports quantity | 0 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Power | |
| Power supply | 310 W |
| Power supply input frequency | 50/60 Hz |
| Power supply input voltage | 100 - 240 V |
| Processor | |
| Efficient cores | 12 |
| Efficient-core base frequency | 1.5 GHz |
| Efficient-core Max Turbo Frequency | 4.2 GHz |
| Maximum turbo power | 219 W |
| Number of processors installed | 1 |
| Performance cores | 8 |
| Performance-core base frequency | 2.1 GHz |
| Performance-core Max Turbo Frequency | 5.3 GHz |
| Processor base power | 65 W |
| Processor boost frequency | 5.4 GHz |
| Processor cache | 33 MB |
| Processor cache type | Smart Cache |
| Processor cores | 20 |
| Processor family | Intel® Core™ i7 |
| Processor generation | Intel® Core™ i7 (14th gen) |
| Processor manufacturer | Intel |
| Processor model | i7-14700 |
| Processor threads | 28 |
| Security | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Password protection | Yes |
| Password protection type | BIOS, HDD, Power on |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system installed | Windows 11 Pro |
| Operating system language | English |
| Storage | |
| Card reader integrated | No |
| Number of SSDs installed | 1 |
| Number of storage drives installed | 1 |
| NVMe | Yes |
| Optical drive type | DVD±RW |
| SSD capacity | 512 GB |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Total storage capacity | 512 GB |
| Sustainability | |
| Sustainability certificates | GREENGUARD, TCO |
| Technical details | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Depth | 297.7 mm |
| Height | 339.5 mm |
| Package depth | 395 mm |
| Package height | 530 mm |
| Package weight | 7.6 kg |
| Package width | 195 mm |
| Weight | 5.3 kg |
| Width | 92.5 mm |
Lenovo ThinkCentre 12V80006FR Intel® Core™ i7 i7-14700 32 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro SFF PC Black
- Brand: Lenovo
- Product Code: 12V40006US
- Availability: In Stock
-
$1,496.66
