58:9 Space-Fitting Wide Screen
The 86BH5F is the most suitable display for delivering new forms of advertising and multiplexed information in a 58:9 widescreen format. It can bring unused & leftover space to life by being installed without restriction.
58:9 Extended Wide Format
It is a unique wide screen with 58:9 bar type which provides much more flexibility in playing content* than the conventional display of 16:9 ratio.
Ultra HD Resolution (3,840 x 600)
Ultra HD resolution delivers an immersive viewing experience with vivid colors and clear images.
Multi Screen Mode with 4PBP
The Picture-by-Picture (PBP) feature allows you to show multi content in one single display by up-to four parts. It is very useful and convenient to deliver various advertisements or pieces of information at the same time without calibration.
Tiled Scene with Immersive View
The 86BH5F can show a tiled scene by up to 15 × 15 configuration. This will be the best choice if you want to use a large screen, or provide visual impact to your customers in a different way.
IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is completely protected from dust, eliminating the risk of performance degradation.
User-Friendly UX
The 86BH5F is equipped with a user-friendly UX to simplify approach flows, groups similar functions together, and adopts an intuitive GUI for ease of use. When using the display in portrait mode, OSD* can also be adjusted accordingly.
LAN Daisy Chain Management
By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
Real-Time Monitoring with LG ConnectedCare
Easier and faster maintenance are available with our optional cloud service solution LG ConnectedCare*. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, ensuring the stable operation of clients' businesses.
The 86BH5F is the most suitable display for delivering new forms of advertising and multiplexed information in a 58:9 widescreen format. It can bring unused & leftover space to life by being installed without restriction.
58:9 Extended Wide Format
It is a unique wide screen with 58:9 bar type which provides much more flexibility in playing content* than the conventional display of 16:9 ratio.
Ultra HD Resolution (3,840 x 600)
Ultra HD resolution delivers an immersive viewing experience with vivid colors and clear images.
Multi Screen Mode with 4PBP
The Picture-by-Picture (PBP) feature allows you to show multi content in one single display by up-to four parts. It is very useful and convenient to deliver various advertisements or pieces of information at the same time without calibration.
Tiled Scene with Immersive View
The 86BH5F can show a tiled scene by up to 15 × 15 configuration. This will be the best choice if you want to use a large screen, or provide visual impact to your customers in a different way.
IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is completely protected from dust, eliminating the risk of performance degradation.
User-Friendly UX
The 86BH5F is equipped with a user-friendly UX to simplify approach flows, groups similar functions together, and adopts an intuitive GUI for ease of use. When using the display in portrait mode, OSD* can also be adjusted accordingly.
LAN Daisy Chain Management
By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
Real-Time Monitoring with LG ConnectedCare
Easier and faster maintenance are available with our optional cloud service solution LG ConnectedCare*. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, ensuring the stable operation of clients' businesses.
| Audio | |
| Built-in speaker(s) | N |
| Computer system | |
| Computer system | Y |
| Design | |
| Orientation | Horizontal/Vertical |
| Panel mounting interface | 600 x 200 mm |
| Placement supported | Indoor |
| Product colour | Black |
| VESA mounting | Y |
| Display | |
| Contrast ratio (dynamic) | 500000:1 |
| Contrast ratio (typical) | 1100:1 |
| Display brightness | 500 cd/m² |
| Display diagonal | 2.18 m (86") |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 600 pixels |
| Haze rate | 3% |
| Panel type | IPS |
| RGB colour space | NTSC |
| Touchscreen | N |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Features | |
| Product design | Digital signage flat panel |
| Purpose | Retail |
| Remote control included | Y |
| Response time | 8 ms |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Memory | |
| Internal memory | 8 GB |
| Network | |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Other features | |
| Special features | CB, NRTL, FCC Class "A", CE, KC, |
| Packaging content | |
| Cables included | AC, DisplayPort, IR, IR sensor |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| USB version | 2.0 |
| Ports & interfaces | |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| DisplayPorts quantity | 2 |
| DVI port | Y |
| DVI-D ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 3 |
| HDMI version | 2.2 |
| Remote (IR) input | 1 |
| RS-232C | Y |
| USB port | Y |
| USB ports quantity | 2 |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Heat dissipation | 751 BTU/h |
| Power consumption (typical) | 220 W |
| Software | |
| Operating system installed | Web OS |
| Sustainability | |
| Sustainability certificates | ErP |
| Weight & dimensions | |
| Bezel width (bottom) | 5.9 mm |
| Bezel width (side) | 4.4 mm |
| Bezel width (top) | 5.9 mm |
| Depth | 81.7 mm |
| Height | 348.5 mm |
| Weight | 20.5 kg |
| Width | 2158.3 mm |
LG 86BH5F-M Signage Display Digital signage flat panel 2.18 m (86") Wi-Fi 500 cd/m² Black Web OS 24/7
- Brand: LG
- Product Code: 86BH5F-M
- Availability: In Stock
-
$3,458.45
