Facilitate higher refresh rates and 8K 60Hz video on UHBR10-enabled DisplayPort devicesConnect an 8K/4K UHD DisplayPort monitor to a host computer or MST hub, using this VESA-Certified DisplayPort 2.1 DP40 Cable. This cable facilitates high bandwidth video and multi-channel audio and is ideal for 8K workstations, high performance GPUs, and dedicated AV applications including media production and content creation.Seamless CompatibilityFor seamless operation between DisplayPort-enabled devices, the DisplayPort 2.1 Cable is VESA Certified for guaranteed DP 2.1 and backward compatibility (DP 2.0/1.4/1.2). It supports G-Sync and FreeSync, enhancing Variable Refresh Rate (VRR) performance for optimal picture quality between high-capacity GPUs and supported displays.Durable DesignThis DisplayPort cable features a flexible TPE outer jacket that is tested to withstand 600 bending cycles at -/+60 degrees, and routes easily around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching nickel-plated DP connectors attach securely to prevent accidental disconnection. The connectors are rated to operate beyond 10,000 insertions.Supported DisplayPort 2.1 Features:This DP40 DisplayPort cable supports the following DP 2.1 features:• Resolutions up to 8K 60Hz w/DSC, using a compatible DP source and display• UHBR10 supports high refresh rates including 4K 120Hz and 1440p 240Hz• High-Bandwidth Digital Content Protection (HDCP) 2.2 for a secure connection between source and display• High Dynamic Range 10 (HDR10) for higher contrast ratio and vibrant picture quality• Display Stream Compression (DSC) 1.2a for maximum resolution output• Multi-Stream Transport (MST) for daisy-chaining multiple monitors• 32 Uncompressed Digital Audio Channels• Backward compatible with previous DP versionsThis DP 2.1 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.The StarTech.com Advantage
Design
Channels quantity 32 channels
Product colour Black
Display
High Dynamic Range (HDR) supported Yes
Maximum refresh rate 240 Hz
Features
AWG wire size 30
Cable length 1.8 m
Cable material Copper
Cable shielding Aluminum mylar foil
Connector 1 DisplayPort
Connector 1 form factor Straight
Connector 1 gender Male
Connector 2 DisplayPort
Connector 2 form factor Straight
Connector 2 gender Male
Connector contacts plating Nickel
Display Stream Compression (DSC) Yes
Display Stream Compression (DSC) version 1.2
Fire-resistance rating VW-1
HDCP Yes
HDCP version 2.2
Jacket material Thermoplastic elastomer (TPE)
Latching connectors Yes
Multi-Stream Transport (MST) Yes
Graphics
Maximum resolution 7680 x 4320 pixels
Logistics data
Master (outer) case height 210 mm
Master (outer) case length 320 mm
Master (outer) case width 500 mm
Products per master (outer) case 50 pc(s)
Operational conditions
Operating relative humidity (H-H) 10 - 85%
Operating temperature (T-T) 0 - 45 °C
Storage temperature (T-T) -20 - 70 °C
Other features
Data transfer rate 40 Gbit/s
Ports & interfaces
DisplayPort version 2.1
Sustainability
Sustainability certificates RoHS
Sustainability compliance Yes
Technical details
Doesn't contain Halogen
Weight & dimensions
Cable diameter 6.5 mm
Package depth 200 mm
Package height 15 mm
Package weight 120 g
Package width 225 mm
Weight 96 g

Write a review

Please login or register to review

StarTech.com 6ft DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz/4K 144Hz w/DSC 1.2a, 40Gbps, DP 2.1 Cable, UHD Monitor Cord, M/M

  • Brand: StarTech.com
  • Product Code: DP21-6F-DP40-CABLE
  • Availability: In Stock
  • $16.46
