Share a mouse, keyboard, USB 5Gbps Hub, and 8K 60Hz DisplayPort monitor between four DisplayPort-enabled computersShare and switch between four USB-A and DisplayPort-enabled computers, using this DisplayPort KVM Switch. Share an 8K 60Hz DisplayPort monitor, a keyboard and mouse, two USB 5Gbps devices, and two additional USB 2.0 devices.High-Resolution 8K 60Hz VideoThis KVM supports resolutions up to 8K 60Hz or 4K 144Hz/120Hz. Daisy chain additional monitors via MST pass-through. The KVM supports ultrawide resolutions of up to 5120x1440 at 60Hz. Ideal for applications such as CAD/CAM, video editing, and content creation. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.Customizable SwitchingThis Universal KVM Switch provides various switching options, including hotkey or push-button switching. Hotkeys allow for independent switching of audio and video, enabling audio playback from one computer while controlling another. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.Universal CompatibilityThe TAA-Compliant KVM Switch offers universal compatibility, working with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.Reliable PerformanceThe durable metal housing helps prevent Electro-magnetic Interference (EMI). Overcurrent Protection (OCP) ensures peripherals don't overdraw power, reducing the occurrence of device dropouts or shutdowns.The StarTech.com Advantage
Design
Hot keys Yes
Housing material Steel
LED indicators Yes
Product colour Black
Push button Yes
Display
Built-in display No
HD type 8K Ultra HD
High Dynamic Range (HDR) supported Yes
Features
Chipset GL-3523
Daisy chain No
Data transfer rate (max) 5000 Gbit/s
HDCP Yes
HDCP version 1.4/2.2
Graphics
Maximum resolution 7680 x 4320 pixels
Logistics data
Master (outer) case height 245 mm
Master (outer) case length 427 mm
Master (outer) case width 545 mm
Products per master (outer) case 60 pc(s)
Operational conditions
Operating relative humidity (H-H) 0 - 85%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 60 °C
Other features
IP control No
Packaging content
Quick installation guide Yes
Rubber feet Yes
Performance
Scan interval 3,8,15,30 s
Ports & interfaces
Audio connections Yes
Console DisplayPorts ports quantity 1
Console ports 3.5mm headphone, DisplayPort, USB A
DC-in jack Yes
DisplayPort version 1.4
DisplayPorts quantity 4
Headphone outputs 4
Keyboard port type USB
Mouse port type USB
Number of computers controlled 4
USB 2.0 Type-A hub ports quantity 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity 4
Video port type DisplayPort
Power
AC input voltage 100 - 240 V
Compatible power plug types EU, JP, UK, US
Input current 1 A
Output current 3 A
Output voltage 12 V
Power consumption (typical) 36 W
Power plug type Type M
Power source DC
Sustainability
Sustainability certificates CE, RoHS, Trade Agreements Act (TAA)
Sustainability compliance Yes
Technical details
Mean time between failures (MTBF) 130000 h
Rack mounting No
Weight & dimensions
Depth 220 mm
Height 44 mm
Package depth 212 mm
Package height 87 mm
Package weight 1.6 kg
Package width 409 mm
Weight 1 kg
Width 130 mm

Write a review

Please login or register to review

StarTech.com 4-Port DisplayPort KVM Switch, 8K 60Hz / 4K 144Hz, Single Display, DP 1.4, 2x USB 3.0 Ports, 4x USB 2.0 HID Ports, Push-Button & Hotkey Switching, TAA Compliant - OS Independent, Metal Housing

  • Brand: StarTech.com
  • Product Code: D86A2-4-PORT-8K-KVM
  • Availability: In Stock
  • $451.82
