Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution. Supplies equipment with continuous power from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
- 15A single phase 120V Basic Power Distribution Unit / PDU
- Attached NEMA 5-15P 15A 120V input plug with 15 ft. / 4.5m line cord
- 0U, 24 in / 61cm vertical form factor supports installation in 2 or 4 post equipment racks
- Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
- 15A single phase 120V Basic Power Distribution Unit / PDU
- Attached NEMA 5-15P 15A 120V input plug with 15 ft. / 4.5m line cord
- 0U, 24 in / 61cm vertical form factor supports installation in 2 or 4 post equipment racks
- Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
| Design | |
| Certification | UL60950-1/CAN/CSA C22.2 No. 60950-1-03 |
| Country of origin | China |
| Housing material | Metal |
| Mounting | Vertical |
| PDU types | Basic |
| Product colour | Black |
| Features | |
| Cable length | 4.57 m |
| Rack capacity | 0U |
| Logistics data | |
| Master (outer) case gross weight | 15.1 kg |
| Master (outer) case GTIN (EAN/UPC) | 10037332122244 |
| Master (outer) case height | 170.2 mm |
| Master (outer) case length | 723.9 mm |
| Master (outer) case width | 365.8 mm |
| Products per master (outer) case | 6 pc(s) |
| Operational conditions | |
| Operating altitude | 0 - 3000 m |
| Storage temperature (T-T) | -15 - 50 °C |
| Other features | |
| Dimensions (WxDxH) | 610 x 43.4 x 44.5 mm |
| Weight (imperial) | 2.36 kg (5.2 lbs) |
| Ports & interfaces | |
| Power plug | NEMA 5–15P |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC outlet types | NEMA 5–15R |
| AC outlets quantity | 14 AC outlet(s) |
| Maximum current | 15 A |
| Nominal input voltage | 100-127 V |
| Nominal output voltage | 100-127 V |
| Sustainability | |
| Sustainability certificates | RoHS |
| Weight & dimensions | |
| Depth | 57.2 mm |
| Height | 44.4 mm |
| Package depth | 718.8 mm |
| Package height | 61 mm |
| Package weight | 2.4 kg |
| Package width | 142.2 mm |
| Weight | 2.09 kg |
| Width | 654 mm |
Tripp Lite 1.8kW Single-Phase Basic PDU, 120V Outlets (14 5-15R), 5-15P, 15ft Cord, 0U Vertical
- Brand: Tripp-Lite
- Product Code: PDU1415
- Availability: In Stock
-
$190.54
