Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution. Supplies equipment with continuous power from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories. Dual independent power circuits offer all the benefits of two PDUs in a single housing, ideal for network equipment fitted with dual redundant input cables.
- 40A total single phase 120V Basic Power Distribution Unit / PDU with dual independent 120V 20A circuits (Agency de-rated to 16A per circuit)
- Functions as two PDUs built into a single 70 in. / 1778mm 0U vertical rackmount housing
- Color coded circuit identification with separate black and gray colored outlets, circuit breakers and line cords
- 40 NEMA 5-15/20R outlets (20 black / 20 gray)
- Two 10 ft. / 3m NEMA L5-20P / 5-20P compatible inputs (1 black / 1 gray)
- Two 20A circuit breakers (1 black / 1 gray)
- Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
- 40A total single phase 120V Basic Power Distribution Unit / PDU with dual independent 120V 20A circuits (Agency de-rated to 16A per circuit)
- Functions as two PDUs built into a single 70 in. / 1778mm 0U vertical rackmount housing
- Color coded circuit identification with separate black and gray colored outlets, circuit breakers and line cords
- 40 NEMA 5-15/20R outlets (20 black / 20 gray)
- Two 10 ft. / 3m NEMA L5-20P / 5-20P compatible inputs (1 black / 1 gray)
- Two 20A circuit breakers (1 black / 1 gray)
- Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
| Design | |
| Certification | UL60950-1 (USA), CSA (Canada) |
| Country of origin | China |
| Housing material | Metal |
| Mounting | Vertical |
| PDU types | Basic |
| Product colour | Black |
| Features | |
| Cable length | 3.05 m |
| Rack capacity | 0U |
| Logistics data | |
| Master (outer) case gross weight | 26.6 kg |
| Master (outer) case GTIN (EAN/UPC) | 10037332128406 |
| Master (outer) case height | 214.9 mm |
| Master (outer) case length | 1860 mm |
| Master (outer) case width | 264.9 mm |
| Products per master (outer) case | 6 pc(s) |
| Operational conditions | |
| Operating altitude | 0 - 3000 m |
| Storage temperature (T-T) | -15 - 50 °C |
| Other features | |
| Dimensions (WxDxH) | 38 x 76 x 1778 mm |
| Weight (imperial) | 3.63 kg (8 lbs) |
| Ports & interfaces | |
| Input connection type | NEMA 5-20P, NEMA L5-20P |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC outlet types | NEMA 5–15, NEMA 5–20R |
| AC outlets quantity | 40 AC outlet(s) |
| Maximum current | 40 A |
| Nominal input voltage | 100-127 V |
| Nominal output voltage | 100-127 V |
| Sustainability | |
| Sustainability certificates | RoHS |
| Weight & dimensions | |
| Depth | 84.8 mm |
| Height | 1784.1 mm |
| Package depth | 1840 mm |
| Package height | 61 mm |
| Package weight | 4.22 kg |
| Package width | 121.9 mm |
| Weight | 3.7 kg |
| Width | 38.1 mm |
Tripp Lite 3.8kW Single-Phase Dual Circuit PDU, 120V 40A Outlets (40 5-15/20R) L5-20P & 5-20P, 2 10ft Cords, 0U Vertical
- Brand: Tripp-Lite
- Product Code: PDU40TDUAL
- Availability: In Stock
-
$309.28
