Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 95% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and optional SNMPWEBCARD network interface. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.
| Battery | |
| Battery recharge time | 4 h |
| Typical backup time at full load | 7.5 min |
| Typical backup time at half load | 21 min |
| Design | |
| Country of origin | China |
| Form factor | Rackmount/Tower |
| LED indicators | Y |
| Product colour | Black |
| Features | |
| Audible alarm(s) | Y |
| Cable length | 3 m |
| Emergency Power Off (EPO) | Y |
| Input frequency | 60 Hz |
| Output power | 1350 W |
| Output power capacity | 1.5 kVA |
| Power factor | 0.9 |
| Rack capacity | 2U |
| Logistics data | |
| Harmonized System (HS) code | 8504.40.8500 |
| Products per master (outer) case | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Other features | |
| Dimensions (WxDxH) | 445 x 343 x 88.9 mm |
| I/O ports | 8 x NEMA 5-15R |
| Non-operating relative humidity (non-condensing) | 0 - 95% |
| Weight (imperial) | 19.7 kg (43.5 lbs) |
| Packaging data | |
| Package dimensions (WxDxH) | 610 x 514 x 229 mm |
| Ports & interfaces | |
| Input connection type | NEMA 5-15P |
| Power | |
| AC outlet types | NEMA 5–15P, NEMA 5–15R |
| AC outlets quantity | 9 AC outlet(s) |
| Nominal input voltage | 120 V |
| Nominal output voltage | 120 V |
| Surge energy rating | 480 J |
| Weight & dimensions | |
| Depth | 341.6 mm |
| Height | 87.6 mm |
| Package depth | 490.2 mm |
| Package height | 223.5 mm |
| Package weight | 24.3 kg |
| Package width | 584.2 mm |
| Weight | 21.1 kg |
| Width | 439.4 mm |
Tripp Lite SMART1500RMXL2U uninterruptible power supply (UPS) 1.5 kVA 1350 W 9 AC outlet(s)
- Brand: Tripp-Lite
- Product Code: SMART1500RMXL2U
- Availability: In Stock
-
$888.43
