Delivering premium backup power and scalable battery runtimes for servers, voice/data networks and storage systems, the Eaton 9PX UPS is the ideal solution for both rack and stand-alone installations. An ENERGY STAR qualified UPS, the 9PX’s graphical LCD interface and robust power management softwaremakes managing your UPS easy — even in virtualized environments.
Battery
Automatic battery test Y
Battery technology Sealed Lead Acid (VRLA)
Cold start Y
Design
Certification IEC 62040-2:2006 Cat C2 / CISPR22 ClassA / FCC part15
Display type LCD
Form factor Rackmount/Tower
LED indicators Y
Product colour Black, Silver
Features
Cable length 1.83 m
Emergency Power Off (EPO) Y
Hot-swap battery Y
Input frequency 50/60 Hz
Input operation voltage (max) 276 V
Input operation voltage (min) 176 V
Input power factor 0.99
Noise level 45 dB
Output operation voltage (max) 240 V
Output operation voltage (min) 120 V
Output power 5400 W
Output power capacity 6 kVA
Output voltage Total Harmonic Distortion (THD) 2%
Power factor 0.9
Rack capacity 6U
Safety CE, cULus, NOM
Surge protection Y
Operational conditions
Operating altitude 0 - 1000 m
Operating relative humidity (H-H) 0 - 95%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 60 °C
Other features
Output connection type 6 x 5-20R & 1 x L6-30R & 1 x L14-30R
Ports & interfaces
Power plug NEMA L6-30P
USB 2.0 ports quantity 1
Power
AC outlet types NEMA 5–20R, NEMA L14-30R, NEMA L6-30R
AC outlets quantity 8 AC outlet(s)
Sustainability
Sustainability certificates RoHS, ENERGY STAR
Weight & dimensions
Depth 721 mm
Height 259 mm
Weight 91 kg
Width 439 mm

Write a review

Please login or register to review

Eaton 9PX uninterruptible power supply (UPS) 6 kVA 5400 W 8 AC outlet(s)

  • Brand: Eaton
  • Product Code: 9PX6KP1
  • Availability: In Stock
  • $6,311.14
