Connect a DisplayPort-equipped PC to a DVI display, with an active 6ft cableThe DP2DVIMM6BS 6ft active DisplayPort to DVI converter cable lets you connect your DisplayPort-equipped desktop or laptop directly to a DVI monitor or projector with no additional adapters or cables required -- a cost-effective solution for enabling your new DisplayPort computer to work with an older DVI monitor or projector.For guaranteed compatibility with virtually any DisplayPort output the active DisplayPort to DVI adapter supports multimode (DP++) as well as single-mode DisplayPort signals. Unlike passive adapters, this ensures the DP2DVIMM6BS can be used with graphics cards that are not capable of outputting multimode DP++ signals, such as ATI® Eyefinity cards.Plus, because the converter cable supports video resolutions up to 1920x1200 you can convert a DisplayPort video source to DVI without sacrificing video quality.The DP2DVIMM6BS is backed by a 3-year StarTech.com warranty and free lifetime technical support.Note:This adapter is not compatible for use with the Apple Cinema Display.
Design
Certification CE, FCC, REACH
Product colour Black
Features
Audio connector N
Cable length 1.8 m
Chipset Parade - PS171
Connector 1 DisplayPort
Connector 1 form factor Straight
Connector 1 gender Male
Connector 2 DVI-D
Connector 2 form factor Straight
Connector 2 gender Male
Converter type Active
Dual Link DVI N
Plug and Play Y
Supported graphics resolutions 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Graphics
Maximum resolution 1920 x 1200 pixels
Logistics data
Harmonized System (HS) code 84733080
Master (outer) case height 435 mm
Master (outer) case length 415 mm
Master (outer) case width 420 mm
Products per master (outer) case 150 pc(s)
Operational conditions
Operating relative humidity (H-H) 40 - 85%
Operating temperature (T-T) 0 - 60 °C
Storage temperature (T-T) -10 - 70 °C
Packaging data
Quantity per pack 1 pc(s)
Ports & interfaces
DisplayPort version 1.2
Sustainability
Sustainability certificates RoHS
Weight & dimensions
Depth 1900 mm
Height 15 mm
Package depth 220 mm
Package height 15 mm
Package weight 123 g
Package width 194 mm
Weight 105.2 g
Width 40 mm

Write a review

Please login or register to review

StarTech.com 6ft (1.8m) DisplayPort to DVI Cable - 1080p Video - Active DisplayPort to DVI Adapter Cable - DisplayPort to DVI-D Cable Single Link - DP 1.2 to DVI Monitor Cable Converter

  • Brand: StarTech.com
  • Product Code: DP2DVIMM6BS
  • Availability: In Stock
  • $30.92
