Tripp Lite's B119-2X2 is a 2x2 HDMI Matrix Switch that routes high definition video from any two HDMI sources to any two HDMI displays. It supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p @ 60Hz. The 2x2 Matrix eliminates the need to disconnect and reconnect HDMI sources. It works with any HDMI source that connects to an HDMI display, and each source is accessible at all times by any display by selecting it with an IR remote, or using the RS232 port to switch the unit.

● Share multiple HDMI sources between multiple monitors ( 2 Input, 2 Output )
● Allows any input to be routed to any output; or the same input to be routed to multiple outputs
● Switch between inputs via pushbuttons, remote control, or RS-232 serial
● Monitors can be located up to 7.6 m from the switch
● Supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p @ 60Hz
● HDCP and EDID compatible
● Mounting hardware included
● Plug-and-play; No software or drivers required
● Compatible with all operating systems

System Requirements
● For international use, a power supply with the appropriate plug type must be purchased separately.
Design
Certification TAA
Country of origin Taiwan
Product colour Black
Features
Full HD Y
HDCP Y
Maximum operating distance 7.62 m
Plug and Play Y
Remote control included Y
Supported graphics resolutions 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Supported video modes 1080p
Logistics data
Master (outer) case gross weight 14.4 kg
Master (outer) case GTIN (EAN/UPC) 10037332180183
Master (outer) case height 297.2 mm
Master (outer) case length 348 mm
Master (outer) case width 589.3 mm
Products per master (outer) case 20 pc(s)
Other features
Dimensions (WxDxH) 233.7 x 99.1 x 30.5 mm
Power requirements 100-240V, 50/60Hz
Packaging content
Manual Y
Packaging data
Quantity per pack 1 pc(s)
Ports & interfaces
DC-in jack Y
HDMI in 2
HDMI ports quantity 4
Number of HDMI outputs 2
RS-232 ports 1
Video port type HDMI
Sustainability
Sustainability certificates RoHS
Weight & dimensions
Depth 99.1 mm
Height 30.5 mm
Package depth 165.1 mm
Package height 55.9 mm
Package weight 680 g
Package width 259.1 mm
Weight 360 g
Width 127 mm

Write a review

Please login or register to review

Tripp Lite 2 x 2 HDMI Matrix Switch for Video and Audio, 1920 x 1200 at 60Hz / 1080p (HDMI 2xF/2xF)

  • Brand: Tripp-Lite
  • Product Code: B119-2X2
  • Availability: In Stock
  • $88.04
